Windows Alternate Data Streams

Anyone who is in the security arena should know about Windows Alternate Data Streams, otherwise known as ADS. Though not highly publicized, lack of this little known attribute of the Windows NTFS file system may affect how you solve a problem in the future.

ADS were introduced into the Windows NTFS file system starting in Windows NT 3.1. This 'feature' was implemented in order to allow compatibility with the Macintosh Hierarchical File System (HFS). In brief, the Macintosh file system stores its data in two parts, the resource fork and the data fork. The data fork is where the data is actually contained and the resource fork is used to tell the operating system how to use the data portion. Windows does a similar thing through extensions such as .bat, .exe, .txt, .html. These extensions tell the operating system how to use the particular data found in the files.

For windows to be compatible with the Macintosh file system, they introduced alternate data streams. This hidden stream is used as the resource fork was used; to tell the system how to use the data contained in the file.

Though ADS was created for compatibility with the Mac world, it is not solely used for that purpose. Many applications use ADS to store attributes of a file in them. For example if you make a text document, and right click and go into its properties you will see a summary page. This summary information is attached to the file via ADS. I will show you more on that later and applications to see this information.

In summary, think of ADS as hidden files that are attached to the visible ones. The main reason they are so dangerous is that they are not well known, are generally hidden to the user, and that there are few security programs that can recognize them.

Before I continue I want to mention some, not all, programs that can be used to view ADS. This is so as you read this tutorial, and follow some examples, you can actually see the ADS files that you are creating.

A new ADS has just been created called hidden.txt and attached to the file test.txt. The ADS file is shown after the : , and : must be used when adding an ADS.

If you wanted to view the ADS hidden.txt, or add information to it, just run notepad to open the file.

Notepad will launch and say this file does not exist and would you like to create it. You would say yes, and then enter the information and save it. This method has just created a new ADS called ads.txt.

ADS files do not have to be attached to a file, but can also be attached a directory. This causes a problem when you create an ADS against a root of a hard drive as it makes it impossible to remove the ADS unless you reformat. If someone knows of a program that can fix this, please let me know.

This command has now attached an ADS to the directory itself. Run LADS to see the ADS attached to the directory.

What if I told you that ADS can also be used with executable files? Thats right, ADS files that are executable can be attached to any file just like you attached .txt files, and just like the text files, would be hidden from most software.

You have now created an ADS file called hidden.exe and attached it to the text file ads.txt. Once again, if you Dir the directory you will just see ads.txt, and not hidden.exe. Run LADS, and you will see the ADS.

There is a caveat to launching executable files that are ADS files. You must always use the START command to launch the ADS executable and you must always use the full path of the file. Here are some examples of working commands and non-working commands.

ADS files are not particularly hard to delete, but they can cause problems. In order to delete an ADS attached to a file, just delete the file. Lets say for example that you have a file called number.txt and there was an ADS attached called hidden.txt. You want to get rid of the hidden.txt file, but keep the info in number.txt, so you just cant delete number.txt.

In order to delete ADS files that are attached to a directory, you need to delete the directory. This can cause a major problem if the ADS is attached to the root of a hard drive. Since you cannot delete the ADS in this way unless you reformat the drive, you can do this to get rid of the unwanted information in the ADS file.

Since I wrote this tutorial there have been a few malware programs that have been released to infect your machine using Alternate Data Stream files. Due to this there have been improvements in the software available to remove these types of programs from your computer. One program that will search for ADS files on your computer and then provide a list that you can remove is ADSSPY. You can find a link to that program below:

In the beginning I mentioned that there are other uses for ADS files. Certain files in Windows have a summary tab in their properties. One example of this is .txt documents. If you create a new .txt doc…
