Reverse Engineering from a 3D Scan with Fusion360... for FREE!

The playlist with load of help videos is https://youtube.com/playlist?list=PLkXjaDpCxSDhsaF-rNq_R2EhkIZz8Tyz_

@LearnEverythingAboutDesign is a fantastic channel, check them out here: - https://www.youtube.com/c/LearnEverythingAboutDesign

For clarity, I am part of the Autodesk Creator program however I have received no direct payment, instruction or help to make this video, it is entirely my own work.

If you'd like to support the channel please check out the Patreon...
https://www.patreon.com/Makingformotorsport

And check out the other socials aswell!
Instagram - making_for_motorsport
Twitter- @Making4msport

00:00 - Intro
01:10 - Scanning
01:50 - What's the goal and simplifying
04:00 - GOM Inspect and aligning to a coordinate system
06:06 - Import into Fusion360
07:56 - Setting an axis - "the process"
12:20 - Revolving the drive flange
15:49 - Using constraints and measurements in the sketch
18:26 - Modeling the steering arm
26:11 - Modelling everything else
27:30 - Summary
