PL583: Turing Machine Half Adder Correction

Apologies for the Sout and Cout bits being the wrong way round.

Also note that the machine's internal states govern what the Turing machine will do next - analogous to an if/else statement in computer programming.

INSTRUCTIONS:

- Go to http://morphett.info/turing/turing.html
- Copy and paste the machine table below into the 'Turing Machine Program' box
- Set the initial state to P
- Set the initial input syntax to a 3 bit value, representing the A, B, and Cin bits respectively. eg: 101 for A=1, B=0, Cin=1
- Press 'reset'
- Run or step the program until it halts.

MACHINE PROGRAM START

P 0 _ r Q
P 1 _ r R

Q 0 0 r W
Q 1 1 r X

X 1 0 * halt
X 0 1 l Y

Y 1 0 * halt

W 1 1 * halt
W 0 0 * halt



R 1 1 r T
R 0 0 r U

U 1 0 l V
U 0 1 * halt

T 1 1 * halt
T 0 0 * halt

V 1 0 * halt
V 0 1 * halt

MACHINE PROGRAM END
