Ladder Logic Basics: XIC & XIO in RSLogix 5000

Ladder Logic Programming Basics - XIC & XIO Instructions in RSLogix 5000
Visit https://SolisPLC.com for more Tutorials, Information & connect with the Community

The XIC, also known as Examine If Closed, instruction is one of the fundamental instructions used in ladder logic programming for Programmable Logic Controllers (PLCs). This instruction is always found on the left side of a ladder rung and will verify if the specified bit is in a logic HIGH state. If that’s the case, the instruction will evaluate to true and allow the rest of the rung to execute.
https://solisplc.com/plc-programming-fundamentals-xic-instruction/

The XIO, also known as Examine If Open, instruction perform the function opposite to the XIC (Examine if Closed). It’s a fundamental instruction for working with Programmable Logic Controllers (PLCs). This instruction can be found on the left side of a ladder logic rung and will evaluate to true if the specified bit is set to a LOW state. If that’s the case, the instruction will allow the rest of the rung to execute.
https://solisplc.com/plc-programming-fundamentals-xio-instruction/
