Double Capacitor Single-Phase Motor: Forward & Reverse 🚗

This video describes a single-phase motor running on 2 capacitors.
Double Capacitor Motor Forward Reverse Connection, Single Phase Motor Forward Reverse

Two capacitors are used in capacitor start capacitor run a motor or two value capacitor motor, one for starting purpose and the other for running purpose. Starting purpose capacitor is of electrolytic type and is disconnected from the supply when the motor attains 75% of synchronous speed with the help of a centrifugal switch.

The Starting Winding must be Switched on .change the motor direction

What is a Centrifugal Switch?

A centrifugal switch is an electrical switch powered by the centrifugal force created by a rotating shaft. This centrifugal force is typically provided by a gasoline engine or electric motor. Centrifugal switches are designed to activate or deactivate the rotational speed of the shaft.

How do Centrifugal Switches work?

A centrifugal switch is an electrical switch normally found in signal phase induction motors and split-phase induction motors.

This switch is used to provide a controlled switching operation that is required in the engine when the specified engine speed is generated.

The centrifugal switch is based on the concept of centrifugal force. It’s just an electric switch. These switches are specially designed for induction motors in single and split phases.

As its operation is identical to that of a centrifugal clutch used in vehicles, the centrifugal switch is generally known as a ‘clutch’.

A single-phase AC engine has a centrifugal switch inside its case, which is attached to the engine shaft. When the engine is off and motionless, the switch is closed.


Thanks for watching the video please subscribe to my channel.
