Assembly Configurations | SOLIDWORKS BEGINNER | Chapter 03: Lesson 05 | CSWA COURSE

Just like parts, assemblies can also have configurations. They can be created through a design table or they can be created manually. While part configurations typically focus on dimensions or features, assembly configurations tend to focus on components, mates, or assembly features. Configurations can be used to represent different versions of a design or can be a powerful way to improve performance, especially when working with large assemblies. In this lesson we will take a look at working with configurations within assemblies.

This lesson uses multiple parts to create an assembly so download the zip file from the link below and extract its contents to an area you can find later. These lesson files were created in SolidWorks 2020, so you will need SW 2020 or newer to open the files and follow the lesson.

Don't forget to like the video and subscribe to the channel to show your support.

TOPICS COVERED
• Accessing the configuration manager
• Configuration properties and advanced settings
• Creating a new configuration
• Adding a sub assembly to a configuration
• Supressing features or parts in a configuration
• Selecting an existing configuration in a sub assembly and defining which configurations to apply to in the main assembly
• Renaming configurations

∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾
EXERCISE FILES - SOLIDWORKS 2020

★Download the lesson part file here:
https://drive.google.com/file/d/1DMdfWsaQlJ-ac6OuLNFieEMAdd0PxqHM/view?usp=sharing

∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾∾

Subscribe for more completely FREE SolidWorks lessons at: https://bit.ly/2GNqkgb

This video is Chapter 03: Lesson 05 of my CSWA (Certified SolidWorks Associate) course which is completely FREE on YouTube. I only ask in return is that if you please like the video and subscribe to the channel to show your support.
