In this video, we dive into the fundamentals of Logic Gates and their corresponding Truth Tables—essential building blocks of digital electronics. Logic gates process binary inputs (0 or 1) and produce a binary output based on logical rules. We cover the most common types of gates, including:

1. **AND Gate**: Produces 1 if all inputs are 1.
2. **OR Gate**: Produces 1 if at least one input is 1.
3. **NOT Gate**: Inverts the input.
4. **NAND Gate**: Opposite of AND gate.
5. **NOR Gate**: Opposite of OR gate.
6. **XOR Gate**: Produces 1 if inputs are different.

You'll also learn how Truth Tables represent the output of each gate for all possible input combinations, helping you understand how these gates work in calculators, computers, and other devices. Ideal for beginners looking to strengthen their knowledge of digital circuits.
