Mastering Subnet Masks in Cybersecurity: Essential Network Skills (Hindi) 🔐

Lecture 9 | Subnet Mask | Cyber security | Network | A2IT | HINDI

Each device has an IP address that consists of two parts: the client or host address and the server or network address. IP addresses are either configured by a DHCP server or configured manually (static IP addresses). The subnet mask divides the IP address into host and network addresses.

The device called a gateway or default gateway connects local devices to other networks. This means that when a local device wants to send information to a device at an IP address on another network, it first sends its packets to the gateway, which then forwards the data on to its destination outside of the local network.

Now Get Free Video Courses, E-Books, Event Updates & Class Notes Anywhere Anytime
LEARN ANYWHERE WITH A2IT IOS AND ANDROID APP
https://a2itsoft.com/free-app
Free Download Educational App with Step-by-Step Guide To Learn or Teach in Smarter Way

Our Websites:
https://www.a2itonline.com
https://www.facebook.com/A2itonline

What is Subnet Mask?
A subnet mask is a 32-bit number created by setting host bits to all 0s and setting network bits to all 1s. In this way, the subnet mask separates the IP address into the network and host addresses.

The IP address, subnet mask and gateway or router comprise an underlying structure—the Internet Protocol—that most networks use to facilitate inter-device communication.

When organizations need additional subnet working, subnetting divides the host element of the IP address further into a subnet. The goal of subnet masks are simply to enable the subnetting process. The phrase “mask” is applied because the subnet mask essentially uses its own 32-bit number to mask the IP address.
IP Address and Subnet Mask

A 32-bit IP address uniquely identifies a single device on an IP network. The 32 binary bits are divided into the host and network sections by the subnet mask but they are also broken into four 8-bit octets.

Because binary is challenging, we convert each octet so they are expressed in dot decimal. This results in the characteristic dotted decimal format for IP addresses—for example, 172.16.254.1. The range of values in decimal is 0 to 255 because that represents 00000000 to 11111111 in binary.
IP Address Classes and Subnet Masks

Since the internet must accommodate networks of all sizes, an addressing scheme for a range of networks exists based on how the octets in an IP address are broken down. You can determine based on the three high-order or left-most bits in any given IP address which of the five different classes of networks, A to E, the address falls within.

(Class D networks are reserved for multicasting, and Class E networks not used on the internet because they are reserved for research by the Internet Engineering Task Force IETF.)

A Class A subnet mask reflects the network portion in the first octet and leaves octets 2, 3, and 4 for the network manager to divide into hosts and subnets as needed. Class A is for networks with more than 65,536 hosts.

A Class B subnet mask claims the first two octets for the network, leaving the remaining part of the address, the 16 bits of octets 3 and 4, for the subnet and host part. Class B is for networks with 256 to 65,534 hosts.

In a Class C subnet mask, the network portion is the first three octets with the hosts and subnets in just the remaining 8 bits of octet 4. Class C is for smaller networks with fewer than 254 hosts.

Class A, B, and C networks have natural masks, or default subnet masks:

Class A: 255.0.0.0
Class B: 255.255.0.0
Class C: 255.255.255.0

You can determine the number and type of IP addresses any given local network requires based on its default subnet mask.

An example of Class A IP address and subnet mask would be the Class A default submask of 255.0.0.0 and an IP address of 43.20.12.2.


Network Addressing

The standard modern network prefix, used for both IPv6 and IPv4, is Classless Inter-Domain Routing (CIDR) notation. IPv4 addresses represented in CIDR notation are called network masks, and they specify the number of bits in the prefix to the address after a forward slash (/) separator. This is the sole standards-based format in IPv6 to denote routing or network prefixes.

To assign an IP address to a network interface since the advent of CIDR, there are two parameters: a subnet mask and the address. Subnetting increases routing complexity, because there must be a separate entry in each connected router’s tables to represent each locally connected subnet.
What Is a Subnet Mask Calculator?

Some know how to calculate subnet masks by hand, but most use subnet mask calculators. There are several types of network subnet calculators. Some cover a wider range of functions and have greater scope, while others have specific utilities.
