Ep 025: Unlocking the Secrets of the XOR Logic Gate 🔍

The fourth logic gate we will examine is the exclusive-OR gate, also known as the XOR gate. There are a couple of ways to look at this interesting gate, both of which result in a device that is useful in many ways including error detection and correction.

Take aways: At the completion of this lesson, each student should be able to:
• define the operation of the XOR gate,
• write the XOR gate truth table,
• show how cascading 2-input XOR gates can be used to create a 3-input XOR gate, and
• identify '⊕' as the XOR operator.
