In this **Class 10 Physics Lecture (Chapter 18 – Electronics, FBISE, National Book Foundation)**, we study **Digital Electronics, Analogue vs Digital Data, and Logic Gates** in detail. Digital electronics is the foundation of all modern devices including **computers, smartphones, calculators, GPS devices, and microcontrollers** like **Arduino and Raspberry Pi**.

Digital circuits work on only **two states – ON/OFF, TRUE/FALSE, HIGH/LOW, or 1/0**. These binary states are the basis of **Boolean algebra**, which uses **Boolean variables** and logical operators such as **AND, OR, and NOT** to perform computations. Just like a light switch can only be ON or OFF, digital circuits use binary digits (bits) to represent data and process information.

### 🔹 Analogue vs Digital Data
- **Analogue signals** are continuous and can take infinite values (e.g., sound, light, temperature).
- **Digital signals** are discrete and represented in binary form (0 or 1).
To connect real-world analogue signals with digital systems, **Analogue-to-Digital Converters (ADC)** are used, while **Digital-to-Analogue Converters (DAC)** are used to convert digital signals back to analogue form.

### 🔹 Units of Digital Data
- Each **binary digit (0 or 1)** is called a **bit**.
- Multiple bits combine to form **bytes**, which are used in computer memory and digital storage.

### 🔹 Logic Gates – Building Blocks of Digital Circuits
**Logic gates** are the basic components of digital circuits. They perform binary operations and are combined to build complex digital systems. Common logic gates include:
- **AND Gate**
- **OR Gate**
- **NOT Gate**
- **NAND & NOR Gates**

Each gate has inputs and one output, defined by a **truth table**. Modern electronic devices are made up of millions of these gates integrated on chips, making them the building blocks of **processors, memory units, and digital communication systems**.

This lecture explains the **difference between analogue and digital data, binary system, data units, ADC/DAC, and logic gates** with examples, helping **FBISE Class 10 Physics students** build a strong foundation in **digital electronics**.
