DC Motor Forward & Reverse Control with Relay 🔄

DC motor forward and reverse controller using relay | relay motor control
This video shows DC motor can be configured to turn in either direction by simply inverting the polarity of the applied voltage. The change in the flow current switches the direction of the spinning force, causing the motor's shaft to begin turning in the opposite direction.
