FreeCAD Beginner Tutorial: Create a Tyre Defect Gauge in 1 Minute

Learn FreeCAD Fast! In this 1-minute tutorial, we’ll create a Tyre Defect Gauge using the Part Design Workbench in FreeCAD. This gauge is used to check defects on rail wheels. We’ll import an image, trace the outline, extrude the shape, and export it as an STL file for 3D printing. Perfect for beginners! 📌 Chapters: 00:00 Intro 00:05 Import & Calibrate Image 00:15 Trace & Adjust Sketch 00:30 Extrude & Apply Fillets 00:45 Export STL 00:55 Outro ✅ Don’t forget to Like, Share & Subscribe for more FreeCAD tutorials! 🔔 Turn on notifications for updates! 📥 Download the reference image file: https://ko-fi.com/s/db8088bd9b #FreeCAD #CADTutorial #3DModeling #FreeCADTutorial #RailwayGauge #3DPrinting #EngineeringDesign #CADCAM #Shorts #FreeCADBeginners
