Basic Motor Control: Jogging Circuit Guide

#accesstopower #motorcontrol
https://accesstopower.com
This video describes and shows how to introduce and wire a jogging circuit into a standard 3 wire start stop motor control circuit. We will show multiple jogging circuit configurations.

Circuit #1 shows a jogging circuit using a 2 position selector switch. Circuit #2 shows a multi-contact pushbutton used to control our jog. Circuit #3 shows our jog controlled by an additional ice cube relay.

In each of these cases, the holding contact on our start-stop circuit is disengaged and the motor can be jogged forward with a momentary press of the jog button.

Check out our blog post for a more detailed description of exactly how each of these circuits work.

https://www.accesstopower.com/blog/basic-motor-control-jogging-circuit
