Ep 025: The XOR Logic Gate

The fourth logic gate we will examine is the exclusive-OR gate, also known as the XOR gate. There are a couple of ways to look at this interesting gate, both of which result in a device that is useful in many ways including error detection and correction. Take aways: At the completion of this lesson, each student should be able to: • define the operation of the XOR gate, • write the XOR gate truth table, • show how cascading 2-input XOR gates can be used to create a 3-input XOR gate, and • identify '⊕' as the XOR operator. #xor #gate #logic #exclusiveor
